Roland JD-Xi

Analog+Digital Crossover Synthesizer

DescriptionImagesSoundsVideoTech specsCompatibleAlternativeFAQRelated ArticlesManualsComments

JD-Xi 1JD-Xi 2JD-Xi 3JD-Xi 4JD-Xi 5
Product Images: click to view fullsize version.
Roland JD-Xi
Roland JD-Xi
550.00 street price

Roland JD-Xi is a hybrid synthesizer, developed as a crossover-concept devicet which includes an analog and digital synthesizer in one housing. The 3-octave instrument is characterized by 4-part multitimbrality. Its analog section consists of a mono DCO with 3 waveforms to choose from, a sub-oscillator (1-2 octaves below), a low-pass filter (LPF) of 24 dB and an analog amplifier (VCA). As for the digital part - it contains two parts: one operates on PCM samples and another is a drum synth. Each of the two digital parts allows 64-note polyphony and is built on a full-featured Roland SuperNatural engine with a depth of editing that is not as amazing as in the FA series, Integra-7 or Jupiter - which are more powerful in piano sounds and have a wider collection of samples, - though still impressive.

JD-Xi is focused on dance music and offers a wide range of 256 digital, 64 analog presets and 32 drum kits (453 drums). You can tweak the settings for editable filter and amplifier envelopes, digital filters, modulation and LFO. Digital components can’t be processed via analog filters or can’t be layered on an analog section, as it is possible to in Roland JD-Xa, but the problem gets somehow solved thanks to a sequencer. JD-Xi has a chic set of effects, including distortion, fuzz, compressor, bitcrush, flanger, phaser, ring modulator, slicer, delay and 6 types of reverb.

This mini synthesizer represents a nice price/quality/functionality ratio. Therefore, its price tag doesn’t fall, although it has already been a while since it was launched, and to boost some public interest, firmware updates with new sounds are being released, as well as special limited series in red and white colors. Buy all three of them, you won’t regret!

Tags: hybrid synthesizer

Country of origin / production: China

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Performance Synthesizer
Usage Design/ Form Factor
With Keys
Archetype
Hybrid, Digital+Analog
Polyphony
Analog Voices1
Digital Voices128
Voices129
Multi Timbral Capacity4 part(s)
Tone Generator / Sound Synthesis
Roland
SuperNATURAL
Oscillators per voice1
Sub-Oscillators per voice1
Waveform/ Spectral form (main generator) Sine
Waveform/ Spectral form (main generator) Pulse Width Modulation (PWM)
Waveform/ Spectral form (main generator) Triangle
Waveform/ Spectral form (main generator) Saw
Filter
High-pass Filter (HPF)
Low-pass Filter (LPF)
Band-pass Filter (BPF)
12dB
24dB
Resonance
Envelope Generator (EG)
Attack
Decay
Sustain
Release
FilterADSR
AmpADSR
Effects
Reverb
Chorus
Compressor
Delay
Vocoder
Bit Crusher/ Crush
Fuzz
Slicer
Ring Modulation
FX Units4
Equalizer
Parametric
Sequencer
Tracks count4
Step Sequencer
Pattern Sequencer
Tempo (min value)5
Tempo (max value)300
Arpegiator/ Portamento
Arpegiator
MIDI
General MIDI v2 (GM2)
General Standard (GS)
MIDI in/ out
IN
OUT
Keys
Type Synth Action
Velocity Sensitivity
Size3
Number of Keys37
Display
Display type TFT
Color resolution Monochrome
Built-in controllers
Pitch Bend Wheel
Modulation Wheel
Encoder1
Potentiometer13
Button48
Audio out
Analogue: 1/4" (6.35mm)4
Analogue: 1/4" (6.35mm) headphones preamplified1
Computer Interfaces
USB USB PC Link
USB MIDI through USB
Power
Amperage1 A
Dimensions
Height85 mm
Width575 mm
Depth245 mm
Height3.4 in
Width12.6 in
Depth9.6 in
Weight2.5 kg
Weight5.5 lb
Case/ body
Plastic
Color
White
Black
Red
Production start2015
