Korg minilogue

Analog Synthesizer

DescriptionImagesSoundsVideoTech specsCompatibleAlternativeFAQRelated ArticlesManualsComments

minilogue 1minilogue 2minilogue 3minilogue 4
Product Images: click to view fullsize version.
Korg minilogue
Korg minilogue
500.00 street price

Korg Minilogue is a modern compact analog synthesizer with digital control.

The structure of the minilogue comprises a low-frequency oscillator (LFO), voltage controlled oscillators (two per voice, 2VCO), a voltage controlled filter (VCF) and an amplifier (VCA). The synthesizer is equipped with two 4-level envelope generators (EG); one is for the amplifier, and the other is for modulation effects. The sub-oscillator - one or two octaves below the master one - is available in mono mode. Powerful effects are represented by ring, pulse width, and cross modulation. There is a synchronization function offered for oscillators.

The generated waveform (saw, triangle and square) can be displayed and observed in real time on a small oscilloscope. In addition, the display shows a menu that helps you to understand any action, since almost every of the synthesizer functions is routed to the front panel controllers, which makes the device intuitive to use and a suitable platform for improvisation.

The sound production process is characterized by a 4-voice polyphony and 8 voice modes: polyphony, duophonic, unison, mono, chord, arpeggiator, chain and voice delay mode which should not be confused with the delay effect - one of the main advantages of this model.

The delay effect is assigned to a separate control unit on the front panel, the first controller of which manages the low-pass filter.

The filter (12 dB and 24 dB) is represented by the cutoff frequency, resonance control and offers an adjustable influence of the envelope generator on the cutoff frequency, as well as the keyboard tracking and velocity sensitivity switches.

With the help of the real time control (Motion Sequence), a variety of modulation effects, analog oscillators, voice modes, details such as noise control, and easily accessible controls, the instrument achieves a rich and specific sound offering numerous combinations.

The 16-step sequencer, which can be set and adjusted in editing mode, records both in real time and stepwise, and each sequence can store up to 4 automation clips.

Korg offers 100 factory presets and the same number of user ones.

The rear panel is equipped with a mini-jack input and output for synchronizing the synthesizer via CV (compatible with Volca, Electribes and SQ-1, as well as other synthesizers), a mono-jack for headphones, audio input (can be processed with filters, envelopes and delay), and MIDI and USB connectors for a computer with MIDI support via USB.

The refined design also attracts attention thanks to its chiseled construction and rich materials: the rear panel is made of wood, the front one is made of a thin sheet of aluminum, while rubber controls and metal switches are quite enjoyable in use.

Tags: analog synthesizer

Country of origin / production: Japan

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Usage Design/ Form Factor
With Keys
Archetype
Analogue (A)
Polyphony
Voices4
Voice Mode Mono
Voice Mode Duo
Voice Mode Poly
Voice Mode Unison
Voice Mode Sidechain
Voice Mode Chord
Voice Mode Delay
Voice Mode Arpegio
Tone Generator / Sound Synthesis
Oscillators per voice2
Waveform/ Spectral form (main generator) Sine
Waveform/ Spectral form (main generator) Pulse Width Modulation (PWM)
Waveform/ Spectral form (main generator) Triangle
Waveform/ Spectral form (main generator) Saw
Waveform/ Spectral form (main generator) White Noise
Programs/ Voices/ Timbres
Single Voice Preset100
User-defined Single Voice100
Filter
2-pole
4-pole
12dB
24dB
Resonance
Envelope Generator (EG)
PitchADSR
AmpADSR
ADSR
Modulation
LFO: LFO Count1
Sequencer
Step Sequencer
Max Step Count16
Arpegiator/ Portamento
Arpegiator
MIDI in/ out
IN
OUT
Keys
Type Synth Action
Mini Keys
Size3
Number of Keys37
Display
Display type OLED
Built-in controllers
Pitch Bend/ Modulation Lever
External controllers
CV/ Gate IN
Audio out
All voices mixed in one output
Analogue: 1/4" (6.35mm)1
Analogue: 1/4" (6.35mm) headphones preamplified1
Audio in
Analog 1/4"1
Computer Interfaces
USB USB PC Link
Power
Voltage 9V
Power Supply External
Power consumption8 W
Dimensions
Height85 mm
Width500 mm
Depth300 mm
Height3.35 in
Width19.69 in
Depth11.81 in
Weight6.17 lb
Weight2.8 kg
Case/ body
Metal&wood
Color
Silver
Production start2015
