Roland D-50

Synthesizer

DescriptionImagesVideoTech specsCompatibleAlternativeFAQRelated ArticlesManualsComments

D-50 1D-50 2
Product Images: click to view fullsize version.
Roland D-50
Roland D-50
700.00 street price

D-50 is one of the most popular digital synthesizers not only ever created by Roland but ever emerged on the market. The 61-note velocity sensitive keyboard with aftertouch was released in 1987. It features 16-voice polyphony which becomes an 8 one in a split or a dual mode. The architecture offers bitimbrality, 32 oscillators providing 2 per voice while in dual or split mode there are 4 per voice available. The synthesis is based on Roland’s Linear Arithmetic technology combined with 8-bit PCM samples onboard. The structure includes 3 LFOs. The filter section is represented with a low pass resonant filter TVF (Time Variant Filter) while the amp is also defined as TVA. Memory stores up to 64 patches.

Roland D-50 received a TEC Award in 1988 beating Yamah DX7 in popularity and waiting for the Korg M1 to come and take its laurels already the next year. D-50 was among the first synths to offer digital chorus and reverb as well as to include sample-based sounds not being a rompler.

D-50 was also unique back then owing to its digital wave generating while many other synths used to fill their structures with complete PCM wave samples. D-50 used PCM to sample acoustic instrument attack nuances as well as delivered samples of famous analog synthesizers processed through the analog path LFO, filter, amp stages.

Tags: digital synthesizer

Country of origin / production: Japan

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Archetype
Digital (D)
Polyphony
Voices16
Multi Timbral Capacity9 part(s)
Tone Generator / Sound Synthesis
Oscillators overall32
Oscillator Type Digital
Technology of Sound Generation PCM
Roland
LAS (Linear Arithmetic Synthesis)
Oscillators per voice2
Programs/ Voices/ Timbres
Patches64
Filter
Low-pass Filter (LPF)
Resonance
MIDI in/ out
IN
OUT
THRU
Keys
Type Synth Action
Velocity Sensitivity
Aftertouch
Size5
Number of Keys61
Built-in controllers
Pitch Bend/ Modulation Lever
Joystick
External controllers
Expression foot pedal
Foot Switch2
Hold
External Control Panel
Audio out
Stereo
All voices mixed in one output
Analogue: 1/4" (6.35mm)2
Analogue: 1/4" (6.35mm) headphones preamplified1
Power
Voltage 230V
Voltage 100V
Voltage 115/117V
Power Supply External
Dimensions
Height94 mm
Width974 mm
Depth332 mm
Weight10.5 kg
Case/ body
Plastic
Metal&plastic
Color
Black
Production start1987
Production end1989
Production ended
