Moog Sub 37

Paraphonic Analog Synthesizer

DescriptionImagesVideoTech specsCompatibleFAQRelated ArticlesManualsComments

Sub 37 1Sub 37 2Sub 37 3Sub 37 4
Product Images: click to view fullsize version.
Moog Sub 37
Moog Sub 37
1 579.00 street price

Moog Sub 37 is a compact analog synthesizer with the big range of sound possibilities.

The sound source compiles 2 oscillators + sub, noise generator and external source.

2 VCO can generate sound together (in mono mode) or in parallel (duophonic). Each oscillator has its own octave switcher and waveform option (from triangle to square, including saw). VCO2 can be synchronised with VCO1 or operate with an interval, a beat freq regulator can set static frequency deviation within 7Hz.

Wide range of possibilities is provided with two LFO (4 waveforms each) and flexible modulation routing options. LFO can be sunchronized with MIDI clock signal and in this case LFO rate is set by the clock divider. Lots of settings are easily accessible thanks to LCD.

VCF is figitally controlled. Cut-off frequency, resonance and modulation depth adjusting is possible as well as key tracking and multidrive which regulates filter overload. You can also choose any of the 1-, 2-, 3- or 4-pole modes.

All the settings can be saved in 256 presets. USB enables editing and preset loading via computer.

Country of origin / production: USA

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Usage Design/ Form Factor
With Keys
Archetype
Analogue (A)
Polyphony
Paraphonic
Analog Voices1
Voice Mode Mono
Voice Mode Duo
Tone Generator / Sound Synthesis
Oscillator Type VCO (Voltage Controlled Oscillator)
Oscillators per voice2
Waveform/ Spectral form (main generator) Pulse Width Modulation (PWM)
Waveform/ Spectral form (main generator) Triangle
Waveform/ Spectral form (main generator) Saw
Waveform/ Spectral form (main generator) Reverse Sawtooth
Waveform/ Spectral form (main generator) White Noise
Programs/ Voices/ Timbres
Patches256
Filter
Voltage Controlled Filter (VCF)
Low-pass Filter (LPF)
24dB
Resonance
Envelope Generator (EG)
Attack
Decay
Sustain
Release
Sequencer
Step Sequencer
Max Step Count64
Arpegiator/ Portamento
Arpegiator
Portamento
MIDI
General MIDI (GM)
MIDI in/ out
IN
OUT
Keys
Type Synth Action
Velocity Sensitivity
Aftertouch
Size3
Number of Keys37
Built-in controllers
Pitch Bend Wheel
Modulation Wheel
Audio out
Mono
Analogue: 1/4" (6.35mm)1
Analogue: 1/4" (6.35mm) headphones preamplified1
Audio in
Analog 1/4"1
Computer Interfaces
USB USB PC Link
USB MIDI through USB
Power
Voltage 100-230(250)V
Voltage 50-60Hz
Power Supply Built-in, internal
Dimensions
Height17.2 mm
Width68 mm
Depth37.5 mm
Weight9.98 kg
Case/ body
Metal&wood
Color
Black
Production start2014
