Elektron Analog Four

4 Voice Polyphonic Analog Tabletop Synthesizer

DescriptionImagesSoundsVideoTech specsCompatibleAlternativeFAQRelated ArticlesComments

Analog Four 1Analog Four 2Analog Four 3
Product Images: click to view fullsize version.
Elektron Analog Four
Elektron Analog Four
1 000.00 street price

Fully analog path, oscillators generating variable waveshape, oscillator AM and Sync modes, analog overdrive circuit, a noise generator, one dedicated vibrato LFO, 2 assignable LFOs and 2 dedicated waveshape ones, 8 envelopes among which there are 2 assignable envelopes, 2 dedicated LFO fade envelopes and one amplifier envelope, a dedicated noise fade envelope, a dedicated vibrato envelope, and a dedicated autobend envelope. LFOs and envelopes represent digital components while oscillators and amplifiers are surely analog.

A 4-voice polyphonic analog synthesizer with a powerful 6-track sequencer is based on 2 oscillators and 2 subs, comprises a 4-pole low-pass ladder type and a 2-pole multi-mode filter. The effects section is represented with a high quality reverb, delay, chorus and overdrive feature. The sequencer allows up to 64 steps per pattern and 128 patterns per project, 6 arpeggiators, individual track parameter adjustment. The instrument delivers convenient Performance mode, instant Pattern, Kit, and Sound reload, full MIDI support.

Control any analog device via 4 CV/Gate outputs which will send Trig and Gate pulses for trigging envelopes, clock pulses for sequencers syncing, control voltages for pitch control. There are CV inputs and a dedicated CV track – the six tracks of the unit’s sequencer include 4 synth tracks, one FX track and one CV track which allows for controlling the signals sent from two CV/Gate outputs.

Analog Four is a smart way of using control voltage and digital precision. You’ll have your sound warm and lively while keep the pitch under accurate control.

Country of origin / production: Sweden

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Sound Module/ Tone Generator
Usage Design/ Form Factor
Without Keys, Desktop
Archetype
Analogue (A)
Polyphony
Voices4
Multi Timbral Capacity4 part(s)
Tone Generator / Sound Synthesis
Oscillator Type DCO (Digitally Controlled Oscillator)
Oscillators overall8
Oscillators per voice2
Oscillators' hard sync
Sub-Oscillators per voice2
Filter
Voltage Controlled Filter (VCF)
High-pass Filter (HPF)
Low-pass Filter (LPF)
2-pole
4-pole
6dB
12dB
Effects
Reverb
Chorus
Delay
Sequencer
Tracks count6
Step Sequencer
Max Step Count64
Pattern Sequencer
Arpegiator/ Portamento
Arpegiator
MIDI
General MIDI (GM)
MIDI in/ out
IN
OUT
THRU
Display
Display type TFT
Resolution: Horizontal122
Resolution: Vertical32
External controllers
CV/ Gate OUT
Audio out
Stereo
All voices mixed in one output
Analogue: 1/4" (6.35mm)2
Analogue: 1/4" (6.35mm) headphones preamplified1
Audio in
Analog 1/4"2
DAC
DAC Frequency 48
Bit24 bit
ADC
Bit24 bit
ADC Frequency 48
Computer Interfaces
USB USB PC Link
USB MIDI through USB
Power
Voltage 12V
Power Supply External
Power consumption24
Amperage2
Dimensions
Height63
Width340
Depth176
Weight2.35 kg
Case/ body
Metal
Color
Black
Production start2012
