Waldorf Wave

Wavetable Digital Synthesizer

DescriptionImagesVideoTech specsFAQRelated ArticlesComments

Wave 1Wave 2Wave 3Wave 4Wave 5Wave 6Wave 7Wave 8
Product Images: click to view fullsize version.
Waldorf Wave
Waldorf Wave
20 000.00 street price

Wave is probably the most refined creation of Waldorf in the history of this German company, which appeared in 1993, in the era of the vector synthesis and workstations. It’s a hybrid synthesizer which has a digital waveform generator based on wavetables, but features analog filters. Wave has 16 to 48 voices (polyphony is expanded by additional cards), an analog bipolar high-pass filter (12dB) and a four-pole low-pass filter (24dB).

The memory of the presets offers 256 multi-timbral programs and 256 single-patches. Wave is equipped with 3 pairs of outputs (main pair and two additional ones), inputs and inputs for third-party audio processing, an input for a sustain pedal and 2 inputs for assignable pedals. The synthesizer has full General MIDI support, in/thru and 2 MIDI outputs.
The 5-octave keyboard is velocity sensitive with aftertouch. Front panel - lifting, with a mass of individual controllers for all provided functions and a large monochrome LCD.

Waldorf Wave operated side by side with PPG Wave 2.2/2.3 and competed with the digital synthesizers Prophet VS, Korg Wavestation, Roland JD-800. Nevertheless, time has put everything in its place and collectors hunt only for this unit and PPG Wave, leaving the Japanese (and even American) mainstream to the amateurs.

The instrument didn’t have a direct successor, except for Microwave XTk. In general, Microwave series had similar, but more humble functionality for a more affordable price (less polyphony, fewer presets, not such a detailed interface, more limited connectivity).

Country of origin / production: Germany

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Performance Synthesizer
Usage Design/ Form Factor
With Keys
Archetype
Digital (D)
Polyphony
Voices48
Tone Generator / Sound Synthesis
Synthesis Method Wavetable
Waveform/ Spectral form (main generator) White Noise
Programs/ Voices/ Timbres
Single Voice Preset256
Multitimbral Preset256
Filter
Voltage Controlled Filter (VCF)
High-pass Filter (HPF)
Low-pass Filter (LPF)
2-pole
4-pole
12dB
24dB
Resonance
Filter auto-oscillation
MIDI
General MIDI (GM)
MIDI in/ out
IN
OUT
THRU
Keys
Type Synth Action
Velocity Sensitivity
Aftertouch
Size5
Number of Keys61
Display
Display type TFT
External controllers
Sustain foot pedal
Foot Controller2
Audio out
Stereo
Analogue: 1/4" (6.35mm)6
Audio in
Analog 1/4"4
Case/ body
Metal&wood
Color
Black
Blue
Production start1993
Production ended
