Modal Electronics 008

8 Voice Analog Synthesizer

DescriptionImagesSoundsVideoTech specsCompatibleAlternativeFAQRelated ArticlesComments

008 1008 2008 3
Product Images: click to view fullsize version.
Modal Electronics 008
Modal Electronics 008
4 900.00 street price

Modulus 008 is an 8-voice analog bi-timbral synthesizer built on discrete components providing 100% voltage control. The instrument offers 2 VCOs and 2 subs per voice allowing you to morph saw, triangle, and square waveforms. You can achieve extreme sound vibes thanks to filter powerful overdrive.

No menu digging, all the mod destinations offer the front panel access. You can choose any destination and set it the way you like limiting yourself with 11 modulation sources one of which is represented with a VCF envelope generator (008 boasts of ultra fast filter and amp envelopes). A 2-track, 32-step sequencer has 16 dedicated step editing knobs and MIDI sync capabilities. The full-function arpeggiator offers a Hold mode which allows to create using a sequencer and arpeggiator together, and an Animator feature which allows to sequence oscillator shifts and filter transitions.

Modulus 008 is updatable via the Ethernet port which enables access to the cloud system. Owing to the cloud you can share your patches with others. Modal Web Interface provides comprehensive external control of the unit’s functions.

The instrument offers a highly responsive screen technology which allows you to get any parameter tweaked with a knob displayed straight away. Create up to 100 banks of quick recalls making an easy-access setlist – 8 quick recall slots are available from the control panel.

The 5-octave semi-weighted Fatar keyboard with aftertouch offers 4 key modes including polyphonic, monophonic, unison and stack.

The connectivity is represented with combined XLR/TRS sockets for balanced/unbalanced outputs. Your computer will recognize 008 as a USB-MIDI device thanks to the optional digital input/output board. There are two audio inputs which process audio starting with the VCF stage. USB-MIDI Host port allows for USB-MIDI devices connecting.

Country of origin / production: United Kingdom

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Usage Design/ Form Factor
With Keys
Polyphony
Voices8
Voice Mode Mono
Voice Mode Poly
Voice Mode Unison
Voice Mode Chord
Multi Timbral Capacity2 part(s)
Tone Generator / Sound Synthesis
Oscillator Type VCO (Voltage Controlled Oscillator)
Oscillators per voice2
Sub-Oscillators per voice2
Filter
Voltage Controlled Filter (VCF)
High-pass Filter (HPF)
Low-pass Filter (LPF)
4-pole
24dB
Resonance
Envelope Generator (EG)
FilterADSR
AmpADSR
Delay+ADSR
Modulation
LFO: LFO Count8
LFO Self-oscillating LFO
Sequencer
Parts count12
Tracks count2
Max Step Count32
Arpegiator/ Portamento
Arpegiator
MIDI
General MIDI (GM)
MIDI in/ out
IN
OUT
THRU
Keys
Type Semi-weighted
Aftertouch
Size5
Number of Keys61
Display
Color resolution 4096 colors/ 12bit
Resolution: Diagonal4.3
Built-in controllers
Joystick
External controllers
Sustain foot pedal
Expression foot pedal
Audio out
Stereo
Dedicated output per voice
All voices mixed in one output
Analogue: XLR2
D-sub
Audio in
Analog 1/4"2
Computer Interfaces
Ethernet
USB USB PC Link
USB USB Storage
USB MIDI through USB
Power
Voltage 100-230(250)V
Voltage 50-60Hz
Power Supply Built-in, internal
Case/ body
Metal
Color
Black
Production start2014
