Sequential Circuits Prophet 5

Analog Programmable Polyphonic Synthesizer

DescriptionImagesSoundsVideoTech specsCompatibleAlternativeFAQRelated ArticlesComments

Prophet 5 1Prophet 5 2Prophet 5 3Prophet 5 4
Product Images: click to view fullsize version.
Sequential Circuits Prophet 5
Sequential Circuits Prophet 5
4 500.00 street price

Prophet 5 is a legend that can surely be added to the list of "top 5 analog synthesizers of all time". Prophet-5 became the most popular professional synthesizer of the late 1970s - early 1980s, and largely influenced the sound of pop music of that period.

Unlike competitors, Prophet-5 has unique software in addition to the perfect analog sound which allows you to save all settings into presets.

This synthesizer was brought up by two amazing legendary people - Dave Smith and John Bowen. Development took them about eight months. The creators say that when devising Prophet-5 they were inspired by the cult Minimoog – and it’s quite obvious.

Prophet-5 has a hybrid structure: the entire audio path is analog, and all control is under the responsibility of the microprocessor.

Voices are placed on separate sound cards. Each voice card contains:

Two voltage controlled oscillators (VCO). There are triangular, square and sawtooth waveforms available. Two oscillators can work in sync and in poly mode, while the second oscillator can be detuned in relation to the first one. Pulse-width (PW) and frequency (FM) modulation are also available.

Voltage controlled low pass filter (LP VCF). It has a four-stage structure with a slope of 24 dB per octave. It also has resonance and cutoff frequency control, it is possible to be modulated by LFO and by a separate ADSR envelope generator.

Voltage controlled amplifier (VCA) modulatable by a built-in ADSR envelope generator, as well as by LFO.

The microprocessor Zilog Z80 has following functions assigned:

VCO calibration

Keyboard scanning

Work with presets

There are three revisions of Prophet-5:

The manually assembled version 1. VCA, VCF electronic elements were based on chips manufactured by SSM. A very small amount was produced.

The second revision was produced until 1980: improvements were made to facilitate operating. Synthesizers of this version were assembled at the factory (the first revision was literally assembled in the garage). Prophet-5 Rev 2 is considered to be the most correct Prophet.

The third version added a cassette interface, the number of presets was increased from 40 to 120, and the SSM chips were replaced with CEM ones. Such a replacement provided greater stability, but at the same time the sound deteriorated. For Rev 3, a MIDI interface is available.

The list of those who did not use Prophet-5 will probably be shorter than those who did. Let's name a few: Modern Talking, Kraftwerk, Radiohead, Public Image Ltd., Duran Duran, No Doubt, Peter Gabriel, Gary Numan, The Prodigy, INXS, The Cars, Phil Collins, Japan, Jaco Pastorius, A-ha, Jean Michel Jarre, Genesis, Eurythmics, Pet Shop Boys, filmmaker/composer John Carpenter.

Country of origin / production: USA

Favorites   Recommend product to a friend

More info
Usage area
Usage Design/ Form Factor
With Keys
Hybrid, Digital+Analog
Analog Voices5
Tone Generator / Sound Synthesis
Oscillator Type VCO (Voltage Controlled Oscillator)
Oscillators' hard sync
Oscillators per voice2
Waveform/ Spectral form (main generator) Pulse Width Modulation (PWM)
Waveform/ Spectral form (main generator) Triangle
Waveform/ Spectral form (main generator) Saw
Programs/ Voices/ Timbres
Voltage Controlled Filter (VCF)
Low-pass Filter (LPF)
Envelope Generator (EG)
Arpegiator/ Portamento
Type Synth Action
Number of Keys61
Display type TFT
Color resolution Monochrome
Built-in controllers
Pitch Bend Wheel
Modulation Wheel
Audio out
Analogue: 1/4" (6.35mm)1
Voltage 100-230(250)V
Voltage 50-60Hz
Power Supply Built-in, internal
Height114 mm
Width952 mm
Depth406 mm
Weight17 kg
Case/ body
Production start1978
Production end1984
Production ended
