Pittsburgh Modular Generator

Dual Oscillator FM

DescriptionImagesTech specsAlternativeFAQRelated ArticlesComments

Generator 1
Product Images: click to view fullsize version.
Pittsburgh Modular Generator
Pittsburgh Modular Generator
229.00 street price

Generator is a kind of a double voltage-controlled oscillator. It does not conform to the 1 volt per octave, and also has no temperature compensation. These factors limit the use of the oscillator, but allow you to create complex FM tones and atonal drum sounds.

Both VCOs produce a triangular wave, have a frequency controller, a three-position range switch and a modulation input.

The input for an external source of FM modulation (External) has an attenuator and a direction switch (VCO1 or 2).

The built-in wave distortion simultaneously controls the waveform of both oscillators and mixes them. At the extreme left position of the "shape" knob, the VCO1 signal will turn into meander, and VCO2 will generate a triangle. At the extreme right – vice versa.

At the bottom of the module there’s a voltage controlled amplifier. It has a CV control input, a sensitivity control and is aimed at processing the VCO1 signal.

Country of origin / production: USA

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Modular System
Usage Design/ Form Factor
Sound Module
Modular Format Eurorack
Type of Sound Module
Voltage Controlled Oscillator (VCO)
Archetype
Analogue (A)
Tone Generator / Sound Synthesis
Synthesis Method Frequency Modulation (FM)
Waveform/ Spectral form (main generator) Square
Waveform/ Spectral form (main generator) Triangle
Audio out
Dedicated output per voice
Analogue: 1/8" (3.5mm)3
Dimensions
Width (Eurorack)10 HP
Case/ body
Metal
Color
Grey
Production start2010
Production ended
