| Usage area | |
|---|---|
| Synthesizer | |
| Usage Design/ Form Factor | |
| With Keys | |
| Archetype | |
| Digital (D) | |
| Polyphony | |
| Voices | 128 |
| Tone Generator / Sound Synthesis | |
| KORG | |
| EDS-X (Enhanced Definition Synthesis-eXpanded) | |
| Programs/ Voices/ Timbres | |
| Single Voice Preset | 1750 |
| User-defined Single Voice | 512 |
| Drum Kits Preset | 107 |
| Drum Kits User-defined | 256 |
| Effects | |
| Reverb | |
| Compressor | |
| Delay | |
| Talk Effects | |
| Insert Effects | 2 |
| Master Effects | 2 |
| Effects overall | 148 |
| Equalizer | |
| Bands | 3 |
| Sampler | |
| Sample Memory | 300 Mb |
| Sequencer | |
| Tracks count | 16 |
| Step Sequencer | |
| Max Events Count | 200000 |
| Output Format | SMF 0 |
| Output Format | SMF 1 |
| Audio Recorder | |
| Recording Format | MP3 |
| Accompaniment | |
| Accompaniment Styles | 430 |
| MIDI | |
| General MIDI (GM) | |
| General Standard (GS) | |
| MIDI in/ out | |
| IN | |
| OUT | |
| Keys | |
| Type | Semi-weighted |
| Velocity Sensitivity | |
| Aftertouch | |
| Size | 5 |
| Number of Keys | 61 |
| Display | |
| Display type | TFT |
| Resolution: Diagonal | 7 |
| Touch Screen | |
| Built-in controllers | |
| Pad | 4 |
| Joystick | |
| Potentiometer | 1 |
| Knob/ Switch | 3 |
| Programmable | |
| Jog dial | |
| External controllers | |
| Foot Controller | 1 |
| Damper pedal | |
| Audio out | |
| Analogue: 1/4" (6.35mm) | 2 |
| Analogue: 1/4" (6.35mm) headphones preamplified | 1 |
| Audio in | |
| Analog 1/4" | 2 |
| Built-in speakers | |
| Stereo, 4 speakers | |
| Amplification power | 2x33 W |
| Computer Interfaces | |
| SSD | |
| USB | USB PC Link |
| USB | USB Storage |
| USB | MIDI through USB |
| External drives/ memory cards | |
| MicroSD (SecureDisk) | |
| Power | |
| Voltage | 100-230(250)V |
| Voltage | 50-60Hz |
| Power Supply | Built-in, internal |
| Power consumption | 25 W |
| Dimensions | |
| Height | 133 mm |
| Width | 1030 mm |
| Depth | 378 mm |
| Weight | 10.75 kg |
| Case/ body | |
| Plastic | |
| Color | |
| Brown | |
| Production start | 2017 |
