Roland INTEGRA-7

Rackmount/ Desktop Sound Module

DescriptionImagesVideoTech specsCompatibleAlternativeFAQRelated ArticlesManualsComments

Product Images: click to view fullsize version.
Roland INTEGRA-7
Roland INTEGRA-7
1 400.00 street price

The device is built upon SuperNATURAL and Behavior Modeling technologies allowing for use the latest sounds cultivated by the brand and recall the sounds quickly owing to the fast access concept. Roland’s flagship keyboards, V-Drums and SRX library have affected the selection of sounds of the 16-part module which contains striking number of sound programs - more than 6000 presets! At the moment this is the maximum number available in any hardware in the history of synth production.

The device has got a new Roland Sound Space derivative technology introduced - Motional Surround – which is presented with a 17-part ambience engine offering a 360-degree control of the position of each part.

The unit delivers over 6000 onboard sounds, multi effects and EQ for each part and dedicated compressor + equalizer for drums and ambience parameters for SuperNATURAL drum kits.

Enjoy the gorgeous selection of grand pianos, electric pianos (including ’68 Reed, ’73 Stage, ’78 Pure, ’76 Tine, and ’81 Tine), guitars, strings, brass and ethnic instruments, as well as synth tones including hundreds of PCM waveforms.

INTEGRA-7 incorporates some surprisingly necessary features such as a Tone Finder wizard, GM2 sound set for playing SMF files via external sequencers, a front-panel USB memory port and a custom iPad Editor App.

Given the market price of INTEGRA-7 and the actual lack of competitors in this segment right now, this sound module finds its niche in professional studios and as part of amateur musicians' setups. The price of the expansion cards, the sounds from which come with INTEGRA-7 as factory presets, is twice bigger than the price of the module itself!

Favorites   Recommend product to a friend

More info
Usage area
Sound Module/ Tone Generator
Usage Design/ Form Factor
Rackmount, 2U
Digital (D)
Multi Timbral Capacity16 part(s)
Tone Generator / Sound Synthesis
Technology of Sound Generation PCM
Motional Surround
FX Units16
MIDI in/ out
Color resolution Monochrome
Resolution: Horizontal256
Resolution: Vertical80
Built-in controllers
Jog dial
Audio out
Analogue: 1/4" (6.35mm)6
Analogue: 1/4" (6.35mm) headphones preamplified1
Analogue: XLR2
Digital: coaxial1
Audio in
Analog 1/4"2
Computer Interfaces
USB USB Storage
Power Supply Built-in, internal
Power consumption18 W
Height89 mm
Width481 mm
Depth262 mm
Height3.6 in
Width18.75 in
Depth10.4 in
Weight3.9 kg
Weight8.10 lb
Case/ body
Production start2012
