Moog Source

Analog Synthesizer

DescriptionImagesVideoTech specsFAQRelated ArticlesComments

Source 1Source 2Source 3Source 4Source 5Source 6Source 7Source 8
Product Images: click to view fullsize version.
Moog Source
Moog Source
1 600.00 street price

Moog Source is a monophonic, monotimbral instrument with an analog subtractive synthesis type. It has 2 oscillators, an LFO, a low pass filter and a storage memory for 16 presets.

The instrument is based on the Z80 microprocessor core. Source was an amusing Minimoog version with flat control panel and the first Moog’s synth allowing for storing patches. VCOs give 3 waveforms, 4-pole analog filter offers keyboard tracking, cutoff frequency, resonance, and envelope setting possibility. LFO and sample&hold are modulation sources. There’s a sequencer onboard.

There was a modified version released by Encore Electronics which implemented MIDI and increased memory.

Source was used by Depeche Mode, New Order (“Blue Monday” track).

Country of origin / production: USA

Favorites   Recommend product to a friend

E-mail*
More info

Usage area
Synthesizer
Usage Design/ Form Factor
With Keys
Archetype
Analogue (A)
Polyphony
Monophonic
Multi Timbral Capacity
Monotimbral
Tone Generator / Sound Synthesis
Oscillators overall2
Oscillator Type VCO (Voltage Controlled Oscillator)
Oscillators per voice2
Waveform/ Spectral form (main generator) Pulse Width Modulation (PWM)
Waveform/ Spectral form (main generator) Triangle
Waveform/ Spectral form (main generator) White Noise
Programs/ Voices/ Timbres
Patches16
Filter
Voltage Controlled Filter (VCF)
Envelope Generator (EG)
FilterADSR
ADSR
Modulation
LFO: LFO Count1
LFO Waveforms
Square
Triangle
Arpegiator/ Portamento
Arpegiator
Keys
Type Synth Action
Size3
Number of Keys37
External controllers
CV in1
Gate in1
CV out1
Gate out1
Power
Voltage 100V
Voltage 120V
Voltage 50-60Hz
Power Supply External
Power consumption30 W
Case/ body
Metal&wood
Color
Silver
Production start1981
Production end1985
Production ended
